Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | Glawall |
| Certification: | SGS, ISO 9001,UL, CE |
| Model Number: | Fully Modular double glass wall |
| Document: | 25mm.pdf |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 10 square maters |
| Price: | US$80.00 10 - 99 square meters |
| Packaging Details: | plywood |
| Delivery Time: | 20-25 days |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Supply Ability: | 3000 square maters per month |
|
Detail Information |
|||
| Advantage: | Competitive Price, Good Service, High Professional, Quality Guarantee | Place Of Origi: | Guangdong, China |
|---|---|---|---|
| Factory Certification: | Yes | Factory Area: | 20000 Square Meter |
| Material: | Aluminum Frame, Acoustic Panels | Soundproofing: | 38-45dB |
| Panel Thickness: | 60, 90.108mm | Glass Type: | Strong Tempered Glass |
| Ventilation: | Airflow System | Warranty: | 2 Years |
| Highlight: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
||
Product Description
| Advantage | Competitive price, good service, high professional, quality guarantee |
| Place of Origin | Guangdong, China |
| Factory Certification | Yes |
| Factory Area | 20000 square meter |
| Material | Aluminum Frame, Acoustic Panels |
| Soundproofing | 38-45dB |
| Panel Thickness | 60, 90, 108mm |
| Glass Type | Strong tempered glass |
| Ventilation | Airflow System |
| Warranty | 2 Years |
| Feature | Benefit |
|---|---|
| Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
| Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
| Tool-Free Connection | Patented click-lock system secures panels without tools |
| Fast Installation | 2-person team can install 20m² in under 3 hours |
| 42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
| Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
| Step | Action |
|---|---|
| Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
| Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
| Step 3 | Snap decorative covers over joints for perfect alignment |
| Feature | Specification |
|---|---|
| Frame | 90mm powder-coated aluminum (20+ RAL colors) |
| Glass | 5+5mm tempered (clear/frosted/tinted options) |
| Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
| Fire Rating | EI30-EI60 available |
| Max Height | 4m without additional support |
| For Contractors | For Clients |
|---|---|
| 70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
| 50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
| No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
