Double Layer Acoustic Glass Partition Wall 38-45dB Soundproofing

Product Details:
Place of Origin:	China
Brand Name:	Glawall
Certification:	SGS, ISO 9001,UL, CE
Model Number:	double glass wall
Document:	25mm.pdf
Payment & Shipping Terms:
Minimum Order Quantity:	10 square maters
Price:	US$80.00 10 - 99 square meters
Packaging Details:	plywood
Delivery Time:	20-25 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	3000 square maters per month

Contact Now

Detail Information
Advantage:	Competitive Price, Good Service, High Professional, Quality Guarantee	Place Of Origi:	Guangdong, China
Factory Certification:	Yes	Factory Area:	20000 Square Meter
Material:	Aluminum Frame, Acoustic Panels	Soundproofing:	38-45dB
Panel Thickness:	60, 90.108mm	Glass Type:	Strong Tempered Glass
Ventilation:	Airflow System	Warranty:	2 Years
Highlight:	double layer acoustic glass partition , soundproof aluminum partition wall , 38-45dB soundproof glass wall

Product Description

Acoustic Partition Wall - Double Layer Sound Reduction System

Premium Soundproofing Solutions

High-performance acoustic partition walls available in 5+5mm glass, 12+12mm glass, or 18+18mm solid panel configurations for superior sound reduction.

Attribute	Value
Advantage	Competitive price, excellent service, professional quality guarantee
Place of Origin	Guangdong, China
Factory Certification	Yes
Factory Area	20,000 square meters
Material	Aluminum Frame, Acoustic Panels
Soundproofing	38-45dB reduction
Panel Thickness	25mm
Glass Type	Strong tempered safety glass
Ventilation	Integrated airflow system
Warranty	2 Years

Understanding Sound Control

Sound is energy created by air disturbances that generate pressure waves. These waves can be airborne (like voices) or impact-based (like footsteps).

Sound waves vibrate at different frequencies (measured in Hertz) with higher frequencies having shorter wavelengths. The vibration strength determines loudness (amplitude), while surface interactions affect reverberation time.

Double-Layer Glass Partition System

Basic Information:

Ideal for high sound insulation requirements, offering excellent performance with structural flexibility.

Construction:

Composed of double-layer tempered glass in aluminum-magnesium alloy frames, fixed with decorative aluminum alloy keels.

Wall Specifications:

Available in 60, 90, 108mm widths with 1.2-2mm wall thickness.

Standard Configurations:

5+5mm, 6+6mm, 12+12mm, or 18+18mm tempered safety clear glass options.

Technical Details:

Extruded aluminum-magnesium alloy profiles with precisely spliced keels and secure buckle fastening.

Color Options:

Standard colors include black, white, silver, gray, with custom options like rose gold available.

Excellent sound insulation performance (38-45dB reduction)
Stable structure with fixed keel reinforcement
Transparent aesthetic with optional frosted or dimmable glass
Modular design allows for disassembly and reuse
Combines privacy and sound control in one solution

Production & Shipping Information

Standard production time: 3-4 weeks for quality manufacturing.

Shipping Options:

EXW (Ex Works): Buyer responsible from our facility
FOB (Free on Board): Responsibility transfers at departure port
CIF (Cost, Insurance, Freight): Includes delivery to destination port
DDU (Delivered Duty Unpaid): Delivery without customs duties
DDP (Delivered Duty Paid): Complete delivery with all duties paid
