Detail Information
Material:	Aluminum Frame	Transparency:	Clear
Factory Certification:	Yes	Factory Area:	20000 Square Meter
Customizable:	Size, Accessories	Competitive Price:	Yes
Glass Thickness:	5mm,6mm, 10mm, 12mm	Advantage:	Competitive Price, Good Service, High Professional, Quality Guarantee
Warranty:	2 Years
Highlight:	aluminum partition wall installation guide , demountable partition wall video tutorial , aluminum partition wall with warranty

Product Description

Professional Installation Process for Demountable Partition Walls

Product Specifications

Material	Aluminum Frame
Transparency	Clear
Factory Certification	Yes
Factory Area	20000 square meter
Customizable	Size, accessories
Competitive Price	Yes
Glass Thickness	5mm, 6mm, 10mm, 12mm
Advantage	Competitive price, good service, high professional, quality guarantee
Warranty	2 Years

About Our Demountable Partition Walls

Demountable partition walls offer flexibility, speed, and precision in space division—whether for offices, co-working spaces, or commercial interiors. Our streamlined installation process ensures seamless assembly, structural integrity, and a flawless finish.

Step-by-Step Installation Guide

1. Planning & Design
✔ Space Assessment	Measure floor plans, ceiling height, and load-bearing requirements
✔ Custom Layouts	Optimize wall placement for privacy, acoustics, and traffic flow
✔ Material Selection	Choose glass, aluminum, or hybrid panel systems

2. Site Preparation
Floor & Ceiling Inspection	Ensure level surfaces (±2mm tolerance)
Clearance & Safety	Remove obstacles, mark electrical/plumbing zones
Modular Grid Mapping	Laser-guided alignment for track positioning

3. Track Installation
Heavy-Duty Aluminum Channels	Anchored to ceiling/floor with seismic-rated brackets
Precision Leveling	Adjustable shims compensate for uneven surfaces
Load Testing	Verified to support 200kg/m² vertical loads

4. Panel Assembly
✔ Pre-Assembled Modules	Glass or solid panels slide into tracks (no welding/gluing)
✔ Acoustic Seals	Silicone gaskets reduce sound transmission by 5-8dB
✔ Tool-Free Adjustments	Cam-lock system enables millimeter-perfect alignment

5. System Integration
Doors & Operable Walls	Pivot/sliding doors installed with auto-latching hardware
Cable Management	Integrated wire channels for power/data
Hybrid Attachments	Compatible with whiteboards, shelving, or green walls

6. Quality Assurance
Laser Alignment Check	Ensures walls are plumb (±1.5mm variance)
Operational Testing	Doors, moving parts, and acoustic seals verified
Client Walkthrough	Final inspection with sign-off protocol

Detailed Installation Steps

Partition up the ceiling
Wall starter installation
Ceiling connection installation
Bottom connection installation
Corner pole installation
Horizontal panel
Vertical panel
Bind panel

Wall Starter Installation & Vertical Adjustment

Regulate the vertical adjusting pole to the vertical position by the M8*30 bolt, and fix it with the side groove by self-tapping screw. Top and bottom groove installation & vertical adjusting pole should be same center line with top and bottom groove.

Corner pole installation
Horizontal panels connection
Vertical panels connection
Blind installation

Each model has a different installation method. We'll provide detailed instructions in PDF format and a video tutorial.

Please contact us to start a chat!

Tag:

Product Details:
Place of Origin:	China
Brand Name:	Glawall
Certification:	SGS, ISO 9001,UL, CE
Model Number:	every style (framed/frameless) double glass
Payment & Shipping Terms:
Minimum Order Quantity:	10 square maters
Price:	US$80.00 10 - 99 square meters
Packaging Details:	plywood
Delivery Time:	25 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	3000 square maters per month
