Detail Information
Model:	Size S, Size M, Size L, Size SL, Size XL, Or Other Customized Size	Place Of Origi:	Guangdong, China
Factory Certification:	Yes	Factory Area:	20000 Square Meter
Material:	Aluminum Frame, Acoustic Panels	Soundproofing:	30+-dB
Privacy Features:	Lockable Door, Soundproofing	Lighting:	LED Ceiling Light
Ventilation:	Airflow System	Warranty:	2 Years
Highlight:	Fire-resistant glass partition wall , Safety fire-resistant glass partition wall

Product Description

All Steel Fire Protection Series Glass Partition Wall Safety Fire-resistant 0

All steel fire protection series:

Stainless steel (304 material) single and double glass fireproof partitions, high-grade zinc steel single and double glass fireproof partitions

This product is an all-steel structure with a wall thickness of 70-125mm, spliced at right angles; the internal vertical and horizontal support frames of the partition are made of zinc steel profile keels; the external frame of the partition is made of 1.0mm environmentally friendly zinc steel alloy profiles or stainless steel profiles, with Class A/ Class C fire-resistant safety glass panels, ordinary safety glass panels, steel composite panels, and fire-resistant expansion sealing strip combined surface installation modules.

Basic parameters:

Wall structure	all steel system
Wall appearance	Duble glazed: wall thickness 70-125mm, upper and lower rail height 25-60mm, glass frame width 25-65mm, module spacing 6mm.
Wall appearance	Singel glazed: wall thickness 65mm, upper and lower rail height 65mm, glass frame width 65mm.
Glass specifications	Class C safety fire-resistant glass with thicknesses of 5, 6mm, and 12mm; Class A safety fire-resistant glass with thicknesses of 25mm, 35mm, 45mm, 55mm, and 65mm.
Module specifications	1200mm
Limit height	top limit 3200mm
Fire resistance limit	EI120min/EI190min
Impact strength	550Nm
Sound isolation load	38dB-48dB

All Steel Fire Protection Series Glass Partition Wall Safety Fire-resistant 1

Available styles	1. All-steel single-layer glass partition system
	2. Double-layer glass partition system (optional louvers)
	3.Double-layer fire-resistant glass partition system (optional blinds)
Features	1. “Meet the fire protection requirements for glass partitions in various commercial office spaces, hospital spaces, and school spaces”
	2. All-steel structure, fire-resistant integrity for 2 hours.
	3. Glawall Partition all-steel fire-resistant glass partition is the third generation + fire-resistant glass partition system. A combination installation module of all-steel profiles and fire-resistant glass/all-steel panels is used for combined installation. Compared with the first generation of frameless fire-resistant glass partitions, it has higher structural reliability and higher fire-resistant integrity performance. Compared with the second generation welded frame fireproof glass partition, it has a more beautiful appearance and is more convenient to install. It has the same appearance as the new aluminum structure glass partition products, achieving perfect first-class quality. All-steel structure partitions are the development direction of commercial partition systems.

All Steel Fire Protection Series Glass Partition Wall Safety Fire-resistant 2

Double-glazed partitions have a long service life and can therefore be reused. And they are generally made of all-steel profiles or aluminum alloy profiles combined with glass, which can be disassembled and replaced to replace the space.

Strong fire resistance	The double-layer design can make it higher quality and have stronger fire resistance, fundamentally eliminating the possibility of fire. The combination of double-layer glass, aluminum alloy and other materials allows it to better isolate the source of fire, ensuring that any danger will not occur within an hour and a half, and has excellent fire resistance.
High security	The double-layer glass design can make the entire glass partition higher quality and safer. In comparison, the double layer is naturally much stronger and more durable than the single layer, so it naturally presents higher safety.
Easy to clean	On the basis of the double-layer design, the cleaning work of the partitions will become easier, because the double-layer design has built-in blinds and adopts a dust-proof design, which can maintain the transparency of the glass for a long time.

There are many advantages of double-glazed partitions. Based on these advantages, excellent development has naturally been achieved. Making this type of partition the first choice for many offices. After all, this design can make the sound insulation effect better and the fire resistance stronger.

All Steel Fire Protection Series Glass Partition Wall Safety Fire-resistant 3

Tag:

Product Details:
Place of Origin:	China
Brand Name:	silent box
Certification:	SGS, ISO 9001,UL, CE
Model Number:	S, M, SL, L, XL
Payment & Shipping Terms:
Minimum Order Quantity:	1 PCS
Price:	1680-4500
Packaging Details:	hard carton package
Delivery Time:	20-25 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	500pcs
